【取证】 内存分析：Windows用户密码获取总结

🧠 内存分析：Windows用户密码获取总结

📋 概述

在Windows内存分析中，用户密码相关信息主要存储在以下三个关键位置：

存储位置 注册表路径 包含信息
SAM 注册表 HKEY_LOCAL_MACHINE\SAM LM Hash、NT Hash
SECURITY 注册表 HKEY_LOCAL_MACHINE\SECURITY\Policy\Secrets 系统自动登录密码（LSA Default Password）、DPAPI 密钥（LSA DPAPI secret）等
SYSTEM 注册表 HKEY_LOCAL_MACHINE\SYSTEM 加解密SAM注册表的SYSKEY、加解密LSA Secrets的LSA key

🎯 核心原理

使用内存分析工具（MemProcFS、Volatility 2、Volatility 3等）获取用户密码相关信息的本质就是读取解析上述三个注册表：

  • SAM 注册表解析 → 获取NT Hash → 需要进一步使用cmd5查询或Hashcat爆破获得明文密码
  • SECURITY 注册表解析 → 获取系统自动登录密码（LSA Default Password）→ 直接获得明文密码

💡 推荐方案：目前使用 MemProcFS 搭配插件 pym_regsecrets 是内存分析中最快、最稳定、最强大的解决方案。

🔍 方法一：MemProcFS + pym_regsecrets插件（推荐）

✨ 优势特点

MemProcFS的核心功能是将内存镜像挂载成可直接访问的文件系统，使分析人员能够像访问磁盘文件一样访问内存数据，从而提取关键信息、检测恶意软件或进行取证调查。

📥 工具下载

工具名称 下载地址
MemProcFS ufrisk/MemProcFS
pym_regsecrets插件 ufrisk/MemProcFS-plugins

🚀 使用方法

1. 基础挂载命令

1
2
3
4
5
6
7
8
# 基础挂载（挂载为M盘）
memprocfs.exe -device c:\temp\win10x64-dump.raw

# 详细输出模式
memprocfs.exe -device c:\temp\win10x64-dump.raw -v

# 取证模式（优化证据解析）
memprocfs.exe -device c:\temp\win10x64-dump.raw -forensic 1

参数说明：

  • -device : 指定内存转储文件路径
  • -v : 启用详细输出模式
  • -forensic 1 : 开启取证模式，优化对内存中潜在证据的解析

2. 查看密码信息

直接访问路径：M:\py\regsecrets\all.txt

📊 输出结果示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
============== SAM hive secrets ==============
HBoot Key: bf97e59957a794d1a7abfcb0cf4cc04310101010101010101010101010101010
Administrator:500:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
Guest:501:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
DefaultAccount:503:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
WDAGUtilityAccount:504:aad3b435b51404eeaad3b435b51404ee:17aaf47842c6fde920d9a73ce8868672:::
Forensix:1001:aad3b435b51404eeaad3b435b51404ee:3ad1b677af07545743b72928fd73fd26:::

============== SECURITY hive secrets ==============
Iteration count: 10240
Secrets structure format : VISTA
LSA Key: a02009c2f2f0e2565448d1e4362e47e9a959f81c38099343393506adb4f8f443
NK$LM Key: 40000000000000000000000000000000cecb266207cac6c41ba4e6f4067a6226d29714067f2b55e598b648878bfb880e29046abd78b48b396e49afa717d571350228ae5a1e108765cf5fe8bf27c201c4be5811a72dad870b5eb2ccf03db7fa70

=== LSA Default Password ===
History: True
Username: UNKNOWN
Password: Welc@me_to-MEMORY

=== LSA DPAPI secret ===
History: False
Machine key (hex): 9b4e4b615826aa6b652e66ffc00c49ba51fb378e
User key(hex): 6ea81f12ed9aca5285c596ce6ef5ebbac1668945

=== LSA DPAPI secret ===
History: True
Machine key (hex): 97c30630f083ad266cdffd8c0b54d8718b786eeb
User key(hex): 166225a7aeeedccc1ea0ebb22ab7c22888dcca61

=== LSASecret NL$KM ===
History: False
Secret:
00000000:  ce cb 26 62 07 ca c6 c4  1b a4 e6 f4 06 7a 62 26   |..&b.........zb&|
00000010:  d2 97 14 06 7f 2b 55 e5  98 b6 48 87 8b fb 88 0e   |.....+U...H.....|
00000020:  29 04 6a bd 78 b4 8b 39  6e 49 af a7 17 d5 71 35   |).j.x..9nI....q5|
00000030:  02 28 ae 5a 1e 10 87 65  cf 5f e8 bf 27 c2 01 c4   |.(.Z...e._..'...|

=== LSASecret NL$KM ===
History: True
Secret:
00000000:  ce cb 26 62 07 ca c6 c4  1b a4 e6 f4 06 7a 62 26   |..&b.........zb&|
00000010:  d2 97 14 06 7f 2b 55 e5  98 b6 48 87 8b fb 88 0e   |.....+U...H.....|
00000020:  29 04 6a bd 78 b4 8b 39  6e 49 af a7 17 d5 71 35   |).j.x..9nI....q5|
00000030:  02 28 ae 5a 1e 10 87 65  cf 5f e8 bf 27 c2 01 c4   |.(.Z...e._..'...|

============== SOFTWARE hive secrets ==============
default_logon_user: Forensix
default_logon_domain:
default_logon_password: None

🔑 关键信息解读

信息类型 示例 说明
NT Hash 3ad1b677af07545743b72928fd73fd26 从SAM hive secrets中提取，可用于cmd5查询或Hashcat爆破
明文密码 Welc@me_to-MEMORY LSA Default Password，直接获得的自动登录明文密码

🧰 方法二：Volatility 2

🔓 获取NT Hash

1
python vol.py -f memory.vmem --profile=Win10x64_19041 hashdump

输出示例：

1
2
3
4
Volatility Foundation Volatility Framework 2.6.1
Administrator:500:aad3b435b51404eeaad3b435b51404ee:481974ce1291ca84c81589a79ee0ff2a:::
Guest:501:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
CaiXX:1000:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::

🔐 获取LSA Secrets

1
python vol.py -f memory.vmem --profile=Win10x64_19041 lsadump

输出示例：

1
2
3
4
5
6
7
8
9
10
Volatility Foundation Volatility Framework 2.6.1
DefaultPassword
0x00000000  00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00   ................
0x00000010  83 99 c8 cf 8b 17 25 c4 04 94 52 e4 cc 7f 3a b1   ......%...R...:.

DPAPI_SYSTEM
0x00000000  2c 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00   ,...............
0x00000010  01 00 00 00 86 f6 78 90 ec 5a cd 60 d2 4b 69 7c   ......x..Z.`.Ki|
0x00000020  cb 79 16 d7 67 c5 46 93 ee f9 a0 13 87 c2 ba 49   .y..g.F........I
0x00000030  7a 93 01 58 6f 43 a9 df fd 4f 62 49 00 00 00 00   z..XoC...ObI....

🧰 方法三：Volatility 3

🔓 获取NT Hash

1
python vol.py -f memory.vmem windows.registry.hashdump

输出示例：

1
2
3
4
5
6
7
8
Volatility 3 Framework 2.26.2
Progress:  100.00               PDB scanning finished
User    rid     lmhash  nthash

Administrator   500     aad3b435b51404eeaad3b435b51404ee        31d6cfe0d16ae931b73c59d7e0c089c0
Guest   501     aad3b435b51404eeaad3b435b51404ee        31d6cfe0d16ae931b73c59d7e0c089c0
DefaultAccount  503     aad3b435b51404eeaad3b435b51404ee        31d6cfe0d16ae931b73c59d7e0c089c0
Forensix        1001    aad3b435b51404eeaad3b435b51404ee        3ad1b677af07545743b72928fd73fd26

🔐 获取LSA Secrets

1
python vol.py -f memory.vmem windows.registry.lsadump

输出示例：

1
2
3
4
5
6
7
8
9
10
11
12
13
Volatility 3 Framework 2.26.2
Progress:  100.00               PDB scanning finished
Key     Secret  Hex

DefaultPassword
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
83 99 c8 cf 8b 17 25 c4 04 94 52 e4 cc 7f 3a b1 ......%...R...:.        00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 83 99 c8 cf 8b 17 25 c4 04 94 52 e4 cc 7f 3a b1

DPAPI_SYSTEM
2c 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ,...............
01 00 00 00 86 f6 78 90 ec 5a cd 60 d2 4b 69 7c ......x..Z.`.Ki|
cb 79 16 d7 67 c5 46 93 ee f9 a0 13 87 c2 ba 49 .y..g.F........I
7a 93 01 58 6f 43 a9 df fd 4f 62 49 00 00 00 00 z..XoC...ObI....        2c 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00 86 f6 78 90 ec 5a cd 60 d2 4b 69 7c cb 79 16 d7 67 c5 46 93 ee f9 a0 13 87 c2 ba 49 7a 93 01 58 6f 43 a9 df fd 4f 62 49 00 00 00 00

🧨 方法四：Mimikatz 离线解密注册表

🔧 前置步骤：挂载内存镜像

1
memprocfs.exe -device c:\temp\win10x64-dump.raw

📁 定位注册表文件

在路径 M:\registry\hive_files\ 下找到以下注册表hive文件：

注册表类型 文件名格式
SYSTEM xxxxxxxxxx-SYSTEM-MACHINE_SYSTEM.reghive
SAM xxxxxxxxxx-SAM-MACHINE_SAM.reghive
SECURITY xxxxxxxxxx-SECURITY-MACHINE_SECURITY.reghive

🔑 Mimikatz 命令操作

1. 获取NT Hash

1
lsadump::sam /system:SYSTEM注册表路径 /sam:SAM注册表路径

完整命令示例：

1
lsadump::sam /system:"M:\registry\hive_files\0xffffa408dac73000-SYSTEM-MACHINE_SYSTEM.reghive" /sam:"M:\registry\hive_files\0xffffa408e400a000-SAM-MACHINE_SAM.reghive"

输出示例：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
mimikatz # lsadump::sam /system:"M:\registry\hive_files\0xffffa408dac73000-SYSTEM-MACHINE_SYSTEM.reghive" /sam:"M:\registry\hive_files\0xffffa408e400a000-SAM-MACHINE_SAM.reghive"
Domain : DESKTOP-A05J24M
SysKey : 78353ea2f42f5ff4e9179b38fa6c7a5f
Local SID : S-1-5-21-3811590110-1262292590-1806065469

SAMKey : bf97e59957a794d1a7abfcb0cf4cc043

RID  : 000001f4 (500)
User : Administrator

RID  : 000001f5 (501)
User : Guest

RID  : 000001f7 (503)
User : DefaultAccount

RID  : 000001f8 (504)
User : WDAGUtilityAccount
  Hash NTLM: 17aaf47842c6fde920d9a73ce8868672

Supplemental Credentials:
* Primary:NTLM-Strong-NTOWF *
    Random Value : 36d64ad2e20fc1de0c3929db859a1a70

* Primary:Kerberos-Newer-Keys *
    Default Salt : WDAGUtilityAccount
    Default Iterations : 4096
    Credentials
      aes256_hmac       (4096) : cd0979355cdfec936ce11d2d736126f8a2f45b5a78a9d862a4441656ebe1a7f2
      aes128_hmac       (4096) : 3f188cc094cea45c037c815b12214c4e
      des_cbc_md5       (4096) : 3d6d1f7a4fdf4383

* Packages *
    NTLM-Strong-NTOWF

* Primary:Kerberos *
    Default Salt : WDAGUtilityAccount
    Credentials
      des_cbc_md5       : 3d6d1f7a4fdf4383

RID  : 000003e9 (1001)
User : Forensix
  Hash NTLM: 3ad1b677af07545743b72928fd73fd26

Supplemental Credentials:
* Primary:NTLM-Strong-NTOWF *
    Random Value : 112b24a01483616d3424c0721e43ca90

* Primary:Kerberos-Newer-Keys *
    Default Salt : DESKTOP-A05J24MForensix
    Default Iterations : 4096
    Credentials
      aes256_hmac       (4096) : ec37e21ff05d56a785294a4da41028e98b4504a0cc66378a6ffbbc3c181efe04
      aes128_hmac       (4096) : 2141b8fc2366706369b067805b5e0c11
      des_cbc_md5       (4096) : 2fef76a8c24fb0e0
    OldCredentials
      aes256_hmac       (4096) : ec37e21ff05d56a785294a4da41028e98b4504a0cc66378a6ffbbc3c181efe04
      aes128_hmac       (4096) : 2141b8fc2366706369b067805b5e0c11
      des_cbc_md5       (4096) : 2fef76a8c24fb0e0

* Packages *
    NTLM-Strong-NTOWF

* Primary:Kerberos *
    Default Salt : DESKTOP-A05J24MForensix
    Credentials
      des_cbc_md5       : 2fef76a8c24fb0e0
    OldCredentials
      des_cbc_md5       : 2fef76a8c24fb0e0

💡 注意：Hash NTLM 对应的值就是NT Hash

2. 获取LSA SECRETS

1
lsadump::secrets /system:SYSTEM注册表路径 /security:SECURITY注册表路径

完整命令示例：

1
lsadump::secrets /system:"M:\registry\hive_files\0xffffa408dac73000-SYSTEM-MACHINE_SYSTEM.reghive" /security:"M:\registry\hive_files\0xffffa408e445f000-SECURITY-MACHINE_SECURITY.reghive"

输出示例：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
mimikatz # lsadump::secrets /system:"M:\registry\hive_files\0xffffa408dac73000-SYSTEM-MACHINE_SYSTEM.reghive" /security:"M:\registry\hive_files\0xffffa408e445f000-SECURITY-MACHINE_SECURITY.reghive"
Domain : DESKTOP-A05J24M
SysKey : 78353ea2f42f5ff4e9179b38fa6c7a5f

Local name : DESKTOP-A05J24M ( S-1-5-21-3811590110-1262292590-1806065469 )
Domain name : WORKGROUP

Policy subsystem is : 1.18
LSA Key(s) : 1, default {a56e94e3-0c3d-209b-a4c2-7c0774acbfb6}
  [00] {a56e94e3-0c3d-209b-a4c2-7c0774acbfb6} a02009c2f2f0e2565448d1e4362e47e9a959f81c38099343393506adb4f8f443

Secret  : DefaultPassword
old/text: Welc@me_to-MEMORY

Secret  : DPAPI_SYSTEM
cur/hex : 01 00 00 00 9b 4e 4b 61 58 26 aa 6b 65 2e 66 ff c0 0c 49 ba 51 fb 37 8e 6e a8 1f 12 ed 9a ca 52 85 c5 96 ce 6e f5 eb ba c1 66 89 45
    full: 9b4e4b615826aa6b652e66ffc00c49ba51fb378e6ea81f12ed9aca5285c596ce6ef5ebbac1668945
    m/u : 9b4e4b615826aa6b652e66ffc00c49ba51fb378e / 6ea81f12ed9aca5285c596ce6ef5ebbac1668945
old/hex : 01 00 00 00 97 c3 06 30 f0 83 ad 26 6c df fd 8c 0b 54 d8 71 8b 78 6e eb 16 62 25 a7 ae ee dc cc 1e a0 eb b2 2a b7 c2 28 88 dc ca 61
    full: 97c30630f083ad266cdffd8c0b54d8718b786eeb166225a7aeeedccc1ea0ebb22ab7c22888dcca61
    m/u : 97c30630f083ad266cdffd8c0b54d8718b786eeb / 166225a7aeeedccc1ea0ebb22ab7c22888dcca61

Secret  : NL$KM
cur/hex : ce cb 26 62 07 ca c6 c4 1b a4 e6 f4 06 7a 62 26 d2 97 14 06 7f 2b 55 e5 98 b6 48 87 8b fb 88 0e 29 04 6a bd 78 b4 8b 39 6e 49 af a7 17 d5 71 35 02 28 ae 5a 1e 10 87 65 cf 5f e8 bf 27 c2 01 c4
old/hex : ce cb 26 62 07 ca c6 c4 1b a4 e6 f4 06 7a 62 26 d2 97 14 06 7f 2b 55 e5 98 b6 48 87 8b fb 88 0e 29 04 6a bd 78 b4 8b 39 6e 49 af a7 17 d5 71 35 02 28 ae 5a 1e 10 87 65 cf 5f e8 bf 27 c2 01 c4

🎯 重要信息：Secret : DefaultPassword old/text: Welc@me_to-MEMORY 就是自动登录密码

🎉 总结

在Windows内存分析中获取用户密码，推荐首选MemProcFS + pym_regsecrets插件的组合方案，该方案具有操作简单、结果全面、稳定性强的优势，能够同时获取NT Hash和明文密码，是目前最优的解决方案。
